MS3391-L Bluetooth 1D Laser Barcode Reader

Specification

MS3391-L small 1D Laser Scanner

Mechanical

Length:57.8mm, Width: 42.3mm, Height:16.4mm

Weight

39g

Electrical

Power: DC5V Typical: 75mA DC5V

CPU

32bit ARM CPU

Data storage

4MB for U disk mode

Working mode

Bluetooth mode, USB output mode, USB virtual COM mode, U disk mode, U disk with Bluetooth mode, U disk with USB mode, Language selection, Date and Time

attached, Buzzer Volume setting.

Scan mode

Good-read off, Momentary, Alternate, Continuous, Host

Artificial light

immunity

100,000 lux

Scanner performance

Sensor Type: Laser Diode 650nm Scanner Rate: 100 times

Scanner Angle: ±50°,±65°,±35°(skew, pitch, Roll)

Contrast: >20%

Decode Speed: 100 times per second

 Battery power

Internal Battery: Rechargeable 600mAh Li-ion Battery, Standby 5 days, working time after full charge with good decode as below:

Charge time: About 1.5 hours

 Barcode Type

UPC-A, UPC-E, UPC-E1, EAN-13(ISBN/ISSN), EAN-8, Code 39(code 32,

Trioptic code 39), Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Codabar,

Code 128, UCC/EAN 128, ISBT 128, Code 93, Code 11, MSI/Plessey, China Post, GS1 DataBar(GS1 DataBar Truncated), GS1 DataBar Limited, GS1 DataBar Expanded.

Decoding depth & Max. resolution

(1 mil = 0.0254 mm)

4 mil: 42- 75 mm

5 mil: 40-105 mm

10 mil: 10-250 mm

15 mil: 23-380 mm

20 mil: 35-490 mm

30 mil: 30-650 mm

55 mil: 75-900 mm

Communication

Class 3 Bluetooth HID, SPP with 20M distance, USB(optional)

OS

IOS, Android, Windows, Mac

Certificate

CE, Rohs, FCC, EN60950, IEC60825, IP64, EMC, 1.5m drop test(500 times).

Laser safety

IEC60825-1-2007, Class 1

Temperature

Operating: -20°C to 60°C (-4°F to 140°F);

Storage: -40°C to 70°C (-40°F to 158°F)

Humidity

5% to 90% (non-condensing)
